Uncompromised Power
High-performance Class-H power amplifier delivering 2200W of studio-grade reliability. Engineered for demanding touring rigs and permanent installations where failure is simply not an option.
| Output Power (8Ω) | 2×550W |
| Output Power (4Ω) | 2×900W |
| Output Power (Bridged 8Ω) | 2200W |
| Frequency Response | 20Hz – 20kHz (±0.5dB) |
| THD+N | <0.05% at 1kHz |
| SNR | >110dB (A-weighted) |
| Input Sensitivity | 0.775V / 1.4V |
| Input Impedance | 20kΩ balanced |
| Cooling | Variable-speed fan, front-to-rear |
| Protection | Clip, thermal, DC, short circuit |
| Form Factor | 2U Rack Mount |
| Weight | 11 kg |
Advanced Class-H topology dynamically tracks the audio signal to maximize efficiency, reducing heat and extending component life under continuous load.
Intelligent front-to-rear variable-speed fan cooling responds to internal temperatures — quiet at idle, powerful under load.
Multi-mode protection against clip overload, thermal runaway, DC offset, and short-circuit conditions safeguards both amplifier and connected speakers.
20kΩ balanced XLR inputs with exceptional common-mode rejection keep noise at bay over long cable runs in live or installed environments.
Heavy-duty binding post speaker outputs rated for sustained high-current delivery — reliable under the most demanding touring conditions.
Transparent clip-limiting circuitry catches transient overload events before they reach speakers, preserving headroom and protecting your investment.
12-channel powered mixer with 600W built-in amplification, 99 DSP presets, and USB media recording for live events.
Explore →
Dual 15-inch passive full-range speaker optimized for high-power applications driven by the LA2200.
Explore →
Dual 12-inch passive loudspeaker with wide dispersion pattern — the ideal passive companion for the LA2200 amplifier.
Explore →Whether you are building a touring backline or a fixed installation, our team will specify the ideal configuration. Contact us for expert consultation.
Worldwide distribution · Professional after-sales support
